Features Delivers up to 30W of PoE+ Surge, peak pulse, and overcurrent protection Contains RJ45 data input, AC cable with earth ground, and PoE+ output LED indicator for status monitoring Technical Specification Output Voltage: 48V DC @ 0.65A Rated Voltage: 100—240V AC @ 50/60Hz AC Input Connector: IEC C5 INLET (Power cord not included) Gigabit LAN Port: Yes 2-pair Powering: Pins 4, 5 (+) and 7, 8 (-) Clamping Protection: 11V Data, 60V power Data In / PoE: RJ45 Shielded Socket Input Current: 0.75A Max. Inrush Current: <150A peak @ 230V AC Efficiency: >87% Switching Frequency: 65 kHz Max. Output Ripple: 1% Max. Line Regulation: ≤ 1% Load Regulation: ≤ 3% Max. Surge Discharge: 1500A (8/20 μs) power Peak Pulse Current: 36A (10/1000 μs) data Response Time: <1 ns Shunt Capacitance: <5 pF data Surge Protection: Difference and Common Mode NDAA Compliant: Yes Dimensions: 93 x 62 x 35 mm Weight: 156 g Compatible with U7-Pro U7-Outdoor U7-Pro-Max U7-Pro-Wall U7-Pro-Outdoor U7-IW U7-Lite U6-Enterprise-IW U6-Enterprise
