Mark: ASRock Model: 90-MXBLL0-A0UAYZ CPU: Supports AMD Socket AM5 Ryzen™ 7000 Series Processors* * Please refer to the CPU support list on ASRock's website for more information. ( http://www.asrock.com/ ) Chipset: AMD A620 Memory: Dual Channel DDR5 Memory Technology - 2 x DDR5 DIMM slots - Supports DDR5 non-ECC and un-buffered memory up to 6400+(OC)* - Max. - Supports Extreme Memory Profile (XMP) and EXTended Profiles for Overclocking (EXPO) memory modules BIOS: Legal 256MB AMI UEFI BIOS with GUI support Graphics: AMD RDNA™ 2 integrated graphics (actual support may vary by CPU) - 1 x HDMI 2.1 TMDS/FRL 8G, supports HDR, HDCP 2.3 and max. resolution up to 4K 120Hz - 1 x DisplayPort 1.4 with DSC (Compressed), supports HDCP 2.3 and max. resolution up to 4K 120Hz Audio: 7.1-channel HD audio (Realtek ALC897 audio codec) - Nahimic Audio LAN: Gigabit LAN 10/100/1000 Mb/s Realtek RTL8111H Slots: CPU: 1 x PCIe 4.0 x16 slot (PCIE1), supports x16 mode* Chipset: 2 x PCIe 3.0 x1 slots (PCIE2 and PCIE3)* 1 x M.2 socket (Key E), supports type 2230 WiFi/BT PCIe WiFi module 15μ Gold Contact on PCIe VGA Slot (PCIE1) Store: CPU: - 1 x Hyper M. 2 socket (M2_1, Key M), supports PCIe Gen4x4 (64Gb/s) type 2280 mode* Chipset: - 1 x M. 2 socket (M2_2, key M), supports type 2260/2280 SATA3 6.0Gb/s and PCIe Gen3x2 (16Gb/s) modes* - 2 SATA3 6.0 Gb/s connectors Raid: Supports RAID 0 and RAID 1 for SATA storage devices Supports RAID 0, RAID 1, and RAID 10 for M.2 NVMe storage devices* USB: 1 x USB 3.2 Gen1 Type-C (Rear) 4 x USB 3.2 Gen1 Type-A (2 rear, 2 front) 6 x USB 2.0 (2 rear, 4 front) Connector: 1 x Power LED and Speaker Connector 1 x CPU fan connector (4-pin)* 3 x Chassis/Water Pump Fan Connectors (4-pin) (Smart Fan Speed ​​Control)** 1 x 24-pin ATX power connector 1 x 8-pin 12V power connector 1 x Front Panel Audio Connector 2 x USB 2.0 connectors (supports 4 USB 2.0 ports) 1 x USB 3.2 Gen1 header (Supports 2 USB 3.2 Gen1 ports) Rear Panel I/O: 2 x Antenna Mounting Points 1 x HDMI port 1 x DisplayPort 1.4 1 x USB 3.2 Gen1 Type-C port 2 x USB 3.2 Gen1 Type-A ports 2 x USB 2.0 ports 1 x RJ 45 LAN port 1 x BIOS Flashback Button HD Audio Connectors: Line In/Front Speaker/Microphone Software and UEFI: Software ASRock Motherboard Utility (A-Tuning) ASRock XFast LAN UEFI ASRock Full HD UEFI ASRock Auto Driver Installer ASRock Instant Flash Accessories: 1 x User Manual 1 x I/O shield 2 x SATA data cables 3 x screws for M.2 sockets
